A voltage regulator normally takes a higher voltage and transforms it into a lower voltage.
The reason to install a voltage regulator is so that you don't have to power it via the USB or 5V input.
In other words to run Smoothieboard standalone via the Panel or Ethernet.
Smoothie's power input is 12-24v and the voltage regulator takes it down to 5V.
Recommended Voltage Regulator (see the More Power section before purchasing the part):
Model: R+78E5.0+0.5 Technical Documents: Spec Sheet
[[http://www.audioholics.com/home-theater-connection/connecting-an-external-amp-to-a-receiver/image|More power]]If you are intending to power a ReprapDiscount Full Graphic LCD controller off 5V power supplied by an on-board regulator, you will most likely need a 1-Amp version of the regulator, as the backlight of the GLCD requires 250mA alone.
Recom part R+78E5.0+1.0 is the same size/pin configuration as the recommended part above.
It is available at Digikey, and likely at other major electronics component sites.
This is how it looks when soldered on:
Red circle marks where it is located
Voltage regulator closeup
Note the orientation
